Bosch
Bosch Climate 5000 L CF
Jednostka wewnętrzna · przypodłogowy
Kod produktu: CL5000iL CF 140 E
PrzypodłogowyTyp
14,1 kWChłodzenie
40 dBHałas (cichy)
Dane techniczne
acoustic
| Noise pressure indoor max dB(A) | 53 dBA |
|---|---|
| Noise pressure indoor medium dB(A) | 50 dBA |
| Noise pressure indoor min dB(A) | 46 dBA |
| Noise pressure indoor silent dB(A) | 40 dBA |
| Sound power indoor dB(A) | 67 dBA |
commercial
| Controller type | Standardowy bezprzewodowy enum_marker |
|---|
electrical
| Current cool max a | 10,3 A |
|---|---|
| Current cool min a | 1,9 A |
| Current cool nominal a | 8,8 A |
| Current heat max a | 10,5 A |
| Current heat min a | 2,1 A |
| Current heat nominal a | 8,9 A |
| Frequency supply hz | 50 Hz |
| Phase count | 1 szt |
| Power input cool max w | 5950 W |
| Power input cool min w | 900 W |
| Power input cool nominal w | 5000 W |
| Power input heat max w | 6050 W |
| Power input heat min w | 1000 W |
| Power input heat nominal w | 5100 W |
| Voltage supply max v | 240 V |
| Voltage supply min v | 220 V |
hydraulic
| Condensate pipe outer diameter mm | 25 mm |
|---|---|
| Pipe diameter gas inch | 5/8 enum_marker |
| Pipe diameter gas mm | 15,9 mm |
| Pipe diameter liquid inch | 3/8 enum_marker |
| Pipe diameter liquid mm | 9,52 mm |
performance
| Airflow indoor max m3h | 2100 m3h |
|---|---|
| Airflow indoor medium m3h | 1850 m3h |
| Airflow indoor min m3h | 1600 m3h |
| Dim depth indoor net mm | 675 mm |
| Dim depth indoor packaging mm | 755 mm |
| Dim height indoor net mm | 235 mm |
| Dim height indoor packaging mm | 313 mm |
| Dim width indoor net mm | 1650 mm |
| Dim width indoor packaging mm | 1725 mm |
| Weight indoor gross kg | 48,5 kg |
| Weight indoor net kg | 41,7 kg |
