Bosch
Bosch Climate 5000 L CF
Jednostka wewnętrzna · przypodłogowy
Kod produktu: CL5000iU CF 70 E
PrzypodłogowyTyp
7,0 kWChłodzenie
32 dBHałas (cichy)
Dane techniczne
acoustic
| Noise pressure indoor max dB(A) | 51 dBA |
|---|---|
| Noise pressure indoor medium dB(A) | 47 dBA |
| Noise pressure indoor min dB(A) | 43 dBA |
| Noise pressure indoor silent dB(A) | 32 dBA |
| Sound power indoor dB(A) | 55 dBA |
commercial
| Controller type | Standardowy bezprzewodowy enum_marker |
|---|
electrical
| Current cool max a | 13,1 A |
|---|---|
| Current cool min a | 3,9 A |
| Current cool nominal a | 10,54 A |
| Current heat max a | 12,7 A |
| Current heat min a | 3,5 A |
| Current heat nominal a | 9,5 A |
| Frequency supply hz | 50 Hz |
| Phase count | 1 szt |
| Power input cool max w | 2930 W |
| Power input cool min w | 747 W |
| Power input cool nominal w | 2300 W |
| Power input heat max w | 2850 W |
| Power input heat min w | 650 W |
| Power input heat nominal w | 2050 W |
| Voltage supply max v | 240 V |
| Voltage supply min v | 220 V |
hydraulic
| Condensate pipe outer diameter mm | 25 mm |
|---|---|
| Pipe diameter gas inch | 5/8 enum_marker |
| Pipe diameter gas mm | 15,9 mm |
| Pipe diameter liquid inch | 3/8 enum_marker |
| Pipe diameter liquid mm | 9,52 mm |
performance
| Airflow indoor max m3h | 1192 m3h |
|---|---|
| Airflow indoor medium m3h | 1023 m3h |
| Airflow indoor min m3h | 853 m3h |
| Dim depth indoor net mm | 675 mm |
| Dim depth indoor packaging mm | 755 mm |
| Dim height indoor net mm | 235 mm |
| Dim height indoor packaging mm | 313 mm |
| Dim width indoor net mm | 1068 mm |
| Dim width indoor packaging mm | 1145 mm |
| Weight indoor gross kg | 33,1 kg |
| Weight indoor net kg | 28 kg |
