LG

LG Mid-ESP Ducted (Commercial)

Jednostka wewnętrzna · kanałowy

Kod produktu: UM24FH.N20

KanałowyTyp
6,8 kWChłodzenie

Dane techniczne

acoustic

Noise pressure indoor medium dB(A)33 dBA
Sound power indoor dB(A)59 dBA

airflow_indoor

Airflow indoor high m3h1680 m3h
Airflow indoor low m3h1260 m3h

capacity

Dehumidification l h1,2 l/h

commercial

Accessory list sourceLG katalog 2026, PDF 143P = druk 285, grupa: Kanałowe (średniego sprężu) text

electrical

Current cool nominal a8,2 A
Current heat nominal a7,8 A
Phase count1 szt
Power input cool nominal w1840 W
Power input heat nominal w1750 W
Voltage supply max v240 V
Voltage supply min v220 V

hydraulic

Condensate pipe inner diameter mm26 mm
Condensate pipe outer diameter mm32 mm
Pipe diameter gas inch5/8 enum_marker
Pipe diameter gas mm15,88 mm
Pipe diameter liquid inch3/8 enum_marker
Pipe diameter liquid mm9,52 mm

noise_indoor

Noise pressure indoor high dB(A)34 dBA
Noise pressure indoor low dB(A)32 dBA

performance

Airflow indoor max m3h1680 m3h
Airflow indoor medium m3h1440 m3h
Dim depth indoor net mm700 mm
Dim height indoor net mm270 mm
Dim width indoor net mm1250 mm
Static pressure external max pa150 Pa
Static pressure external min pa25 Pa
Weight indoor net kg39,3 kg

power_indoor

Power input indoor high w134 W
Power input indoor low w80 W
Power input indoor medium w101 W
