LG

LG Mid-ESP Ducted (Commercial)

Jednostka wewnętrzna · kanałowy

Kod produktu: UM12FH.N10

KanałowyTyp
3,5 kWChłodzenie

Dane techniczne

acoustic

Noise pressure indoor medium dB(A)32 dBA
Sound power indoor dB(A)56 dBA

airflow_indoor

Airflow indoor high m3h990 m3h
Airflow indoor low m3h780 m3h

capacity

Dehumidification l h0,4 l/h

commercial

Accessory list sourceLG katalog 2026, PDF 143P = druk 285, grupa: Kanałowe (średniego sprężu) text

electrical

Current cool nominal a4,6 A
Current heat nominal a4,3 A
Phase count1 szt
Power input cool nominal w1030 W
Power input heat nominal w980 W
Voltage supply max v240 V
Voltage supply min v220 V

hydraulic

Condensate pipe inner diameter mm26 mm
Condensate pipe outer diameter mm32 mm
Pipe diameter gas inch3/8 enum_marker
Pipe diameter gas mm9,52 mm
Pipe diameter liquid inch1/4 enum_marker
Pipe diameter liquid mm6,35 mm

noise_indoor

Noise pressure indoor high dB(A)34 dBA
Noise pressure indoor low dB(A)30 dBA

performance

Airflow indoor max m3h990 m3h
Airflow indoor medium m3h870 m3h
Dim depth indoor net mm700 mm
Dim height indoor net mm270 mm
Dim width indoor net mm900 mm
Static pressure external max pa150 Pa
Static pressure external min pa20 Pa
Weight indoor net kg25,4 kg

power_indoor

Power input indoor high w150 W
Power input indoor low w110 W
Power input indoor medium w130 W
