MHI
MHI SRR
Jednostka wewnętrzna · kanałowy
Kod produktu: SRR35ZS-W
KanałowyTyp
3,5 kWChłodzenie
25 dBHałas (cichy)
Dane techniczne
acoustic
| Noise pressure indoor medium dB(A) | 34 dBA |
|---|---|
| Noise pressure indoor silent dB(A) | 25 dBA |
| Sound power indoor dB(A) | 57 dBA |
electrical
| Phase count | 1 szt |
|---|---|
| Power input cool nominal w | 930 W |
| Power input heat nominal w | 1010 W |
| Voltage supply max v | 240 V |
| Voltage supply min v | 220 V |
hydraulic
| Pipe diameter gas mm | 9,52 mm |
|---|---|
| Pipe diameter liquid mm | 6,35 mm |
noise_indoor
| Noise pressure indoor high dB(A) | 38 dBA |
|---|---|
| Noise pressure indoor low dB(A) | 31 dBA |
performance
| Airflow indoor cool max m3h | 600 m3h |
|---|---|
| Airflow indoor max m3h | 600 m3h |
| Dim depth indoor net mm | 500 mm |
| Dim height indoor net mm | 200 mm |
| Dim width indoor net mm | 750 mm |
| Static pressure external max pa | 35 Pa |
| Static pressure external nominal pa | 5 Pa |
| Weight indoor net kg | 20,5 kg |
