LG
LG Low-ESP Ducted (Commercial)
Jednostka zewnętrzna
Kod produktu: UUB1.U20
Dane techniczne
acoustic
| Noise pressure outdoor cool dB(A) | 47 dBA |
|---|---|
| Noise pressure outdoor heat dB(A) | 52 dBA |
| Sound power outdoor cool dB(A) | 63 dBA |
airflow_outdoor
| Airflow outdoor max m3h | 3000 m3h |
|---|
electrical
| Phase count | 1 szt |
|---|---|
| Power supply cross section mm2 | 2,5 mm2 |
| Power supply fuse a | 20 A |
| Power supply wires | 3 szt |
| Voltage supply max v | 240 V |
| Voltage supply min v | 220 V |
fan_outdoor
| Fan count outdoor | 1 szt |
|---|
hydraulic
| Pipe height diff max m | 30 m |
|---|---|
| Pipe length max m | 30 m |
| Pipe length min m | 5 m |
| Refrigerant charge additional g m | 20 g/m |
| Refrigerant charge factory kg | 1,2 kg |
| Refrigerant co2 equivalent t | 0,81 t |
| Refrigerant gwp | 675 ratio |
| Refrigerant precharge distance m | 10 m |
| Refrigerant type | R32 enum_marker |
performance
| Airflow outdoor m3h | 3000 m3h |
|---|---|
| Compressor type | PodwĂłjna rotacyjna enum_marker |
| Dim depth outdoor net mm | 330 mm |
| Dim height outdoor net mm | 650 mm |
| Dim width outdoor net mm | 870 mm |
| Weight outdoor net kg | 44,5 kg |
seasonal
| Operating temp cool max c | 50 °C |
|---|---|
| Operating temp cool min c | 15 °C |
| Operating temp heat max c | 18 °C |
| Operating temp heat min c | 20 °C |
