Fujitsu Multi Split
Fujitsu

Fujitsu Multi Split

Jednostka zewnętrzna · do 5 jednostek

Kod produktu: AOEG36KBTA5

do 5Jednostek wewn.
9,5 kWChłodzenie
7,80SEER
4,30SCOP

Dane techniczne

acoustic

Noise pressure outdoor cool dB(A)52 dBA
Noise pressure outdoor heat dB(A)55 dBA
Sound power outdoor dB(A)68 dBA

airflow_outdoor

Airflow outdoor max m3h2900 m3h

capacity

Capacity cool nominal kW9,5 kW
Capacity heat nominal kW10,6 kW

hydraulic

Pipe height diff max m15 m
Pipe length max m75 m
Refrigerant charge factory kg2,5 kg
Refrigerant co2 equivalent t1,688 t
Refrigerant gwp675 ratio
Refrigerant typeR32 enum_marker

performance

Dim depth outdoor net mm315 mm
Dim height outdoor net mm884 mm
Dim width outdoor net mm820 mm
Max connectable indoor units5 szt
Weight outdoor net kg59 kg

seasonal

Operating temp cool max c46 °C
Operating temp cool min c-10 °C
Operating temp heat max c24 °C
Operating temp heat min c-15 °C
